The persistence of cancerous cells after treatment, known as measurable or minimal residual disease (MRD), may lead to relapse1,2

Even after morphologic complete remission (CR), small traces of malignant cells can remain and lead to relapse, limited treatment options, and poor patient outcomes in acute lymphoblastic leukemia (ALL) and multiple myeloma.3,4

Evolving science and knowledge of MRD as a key prognostic indicator is shaping treatment choices and overall patient management.3

As part of our ongoing commitment to improving patient outcomes, Amgen continues to explore innovative approaches for eradicating MRD across multiple hematologic malignancies. Amgen is leading the way in MRD(+) B-cell precursor ALL and is committed to advancing the science to fulfill our mission of serving patients.

MRD IN ALL MRD IN MULTIPLE MYELOMA

MRD IN ACUTE LYMPHOBLASTIC LEUKEMIA

Going deeper by measuring MRD

In ALL, measurable residual disease (MRD) is defined as the presence of detectable leukemic cells within the bone marrow during morphologic CR.5 The definition of MRD positivity has yet to be standardized, but a sensitivity threshold of 10-4 (or 0.01%, 1 cancer cell in 10,000 normal cells) is commonly used and may guide clinical outcomes.6

A substantial proportion of adult patients with ALL relapse despite achieving morphologic CR, with a reported relapse rate of 40%–50%.7 Furthermore, patients may still have detectable residual disease despite achieving CR with morphological testing.8

  • Approximately 30%–40% of patients who achieve CR may still test positive for MRD1,9,10,*

MRD as a prognostic indicator

Measurable residual disease (MRD) is a strong prognostic indicator for survival outcomes and relapse in ALL.3,8

  • In a meta-analysis (N=13,637), the presence of MRD after induction or consolidation therapy was associated with negative outcomes.3,† A significant benefit was seen in overall survival (OS) in adult and pediatric patients with ALL who achieved MRD negativity3

Impact of MRD status on OS: Adult ALL3

Impact of MRD status on OS: Adult ALL

Impact of MRD status on OS: Pediatric ALL3

Impact of MRD status on OS: Pediatric ALL

  • Additionally, a retrospective study observed that MRD positivity at the time of allogeneic hematopoietic stem cell transplantation (HSCT) in first CR was significantly associated with hematologic relapse11,‡

Cumulative incidence of hematologic relapse based on MRD status11

Cumulative incidence of hematologic relapse based on MRD status

Detecting MRD

NCCN Clinical Practice Guidelines in Oncology (NCCN Guidelines®) for ALL state that a bone marrow sample from the first or early small-volume (up to 3 mL) pull is preferred for measurable residual disease (MRD) testing.12

There are 3 common techniques used to quantify MRD in ALL:13

Flow cytometry
Target
Aberrant leukemia-associated immunophenotypes13
Typical sensitivity
1 cancer cell in 10,000 normal cells13
Additional considerations
Baseline sample preferred but not required13

Fresh sample necessary13
Quantitative polymerase chain reaction
Target
Immunoglobulin/T-cell receptor gene rearrangements or abnormal gene fusions (eg, BCR-ABL1)14
Typical sensitivity
1 cancer cell in 10,000 normal cells13
Additional considerations
Baseline sample required13,§
Next-generation sequencing
Target
Immunoglobulin/T-cell receptor gene rearrangements13
Typical sensitivity
1 cancer cell in 1,000,000 normal cells13
Additional considerations
Baseline sample required13
Flow cytometry Quantitative polymerase chain reaction Next-generation sequencing
Target Aberrant leukemia-associated immunophenotypes13 Immunoglobulin/T-cell receptor gene rearrangements or abnormal gene fusions (eg, BCR-ABL1)14 Immunoglobulin/T-cell receptor gene rearrangements13
Typical sensitivity 1 cancer cell in 10,000 normal cells13 1 cancer cell in 100,000 normal cells13 1 cancer cell in 1,000,000 normal cells13
Additional considerations Baseline sample preferred but not required13

Fresh sample necessary13
Baseline sample required13,§ Baseline sample required13

NCCN Guidelines® recommend testing for MRD

NCCN Guidelines state that measurable residual disease (MRD) is an essential component of patient evaluation over the course of sequential therapy in pediatric and adult patients with ALL.12,15,**

MRD testing timeline12,15

MRD testing timelineMRD testing timeline

Get more facts about MRD testing for your practice

An infographic resource that provides an overview of measurable residual disease (MRD) in ALL, including facilities that conduct MRD testing.
A fact sheet with more information about MRD in ALL, including various detection methods.

A list of CLIA-certified external facilities that test for MRD in ALL.

*Range based on three clinical studies in which MRD was measured at different time points.1,9,10

According to a meta-analysis of 39 publications of distinct studies with 13,637 patients.3

According to a retrospective study evaluating the cumulative incidence of hematologic relapse in 257 patients with Ph(+) ALL who underwent HSCT in first CR.11

§A baseline sample is only needed for Ig/TCR gene rearrangements. A baseline sample is not required for abnormal gene fusions.13

**AYA patients can be included in either pediatric or adult patient populations.12,15

††Dependent on MRD testing technique used.12,15

‡‡Additional time points should be guided by the regimen used. Serial monitoring frequency may be increased in patients with molecular relapse or persistent low-level disease burden.12,15

§§Additional time points should be guided by the regimen used.15

***MRD testing may be included with a bone marrow aspirate.15

MRD IN MULTIPLE MYELOMA

Clinical relevance of MRD

Minimal residual disease (MRD) in multiple myeloma refers to the presence of residual myeloma cells in the bone marrow after an observed response.2,4 The 2016 International Myeloma Working Group (IMWG) consensus criteria recommends a minimum sensitivity of 10-5 when defining MRD negativity.4 The presence of MRD may lead to disease progression and relapse in multiple myeloma.4

MRD as a prognostic indicator

Minimal residual disease (MRD) is a prognostic indicator for survival outcomes in multiple myeloma.16

  • In a meta-analysis, MRD negativity was associated with improved PFS (n=1,273) and OS (n=1,100) in patients with multiple myeloma16,†††,‡‡‡

Impact of MRD status on PFS in multiple myeloma16

Impact of MRD status on PFS in multiple myeloma

Impact of MRD status on OS in multiple myeloma16

Impact of MRD status on OS in multiple myeloma

  • Additionally, a recent meta-analysis of 6 studies (N=3,283) in patients with newly diagnosed multiple myeloma (NDMM) observed that MRD negativity was associated with improved PFS, supporting MRD as a surrogate endpoint for PFS in clinical trials17,§§§

Detecting MRD

There are several techniques used to quantify minimal residual disease (MRD) in multiple myeloma:

Flow cytometry
Target
Normal versus abnormal plasma cells through detection of cell-surface marker expression18
Peak sensitivity
1 cancer cell in 1,000,000 normal cells19
Additional considerations

No baseline sample required19

Fresh sample necessary19

Requires bone marrow aspirate18
ASO-PCR
Target
VDJ heavy chain regions for detection of immunoglobulin rearrangements18
Peak sensitivity
1 cancer cell in 1,000,000 normal cells19
Additional considerations

Baseline sample required19

Fresh sample not necessary19

Requires bone marrow aspirate18
Next-generation sequencing
Target
Clonal immunoglobulin VDJ gene rearrangements18
Peak sensitivity
1 cancer cell in 1,000,000 normal cells19
Additional considerations

Baseline sample required19

Fresh sample not necessary19

Bone marrow aspirate or peripheral blood sample acceptable18
PET/CT
Target
Detection of lesions demonstrating metabolic activity along with morphologic information; detection of extramedullary disease4,19
Peak sensitivity
Variable19
Additional considerations
N/A
Flow cytometry ASO-PCR Next-generation sequencing PET/CT
Target Normal versus abnormal plasma cells through detection of cell-surface marker expression18 VDJ heavy chain regions for detection of immunoglobulin rearrangements18 Clonal immunoglobulin VDJ gene rearrangements18 Detection of lesions demonstrating metabolic activity along with morphologic information; detection of extramedullary disease4,19
Peak sensitivity 1 cancer cell in 1,000,000 normal cells19 1 cancer cell in 1,000,000 normal cells19 1 cancer cell in 1,000,000 normal cells19 Variable19
Additional considerations No baseline sample required19

Fresh sample necessary19

Requires bone marrow aspirate18
Baseline sample required19

Fresh sample not necessary19

Requires bone marrow aspirate18
Baseline sample required19

Fresh sample not necessary19

Bone marrow aspirate or peripheral blood sample acceptable18
N/A

Applications of MRD in multiple myeloma

Response criteria in multiple myeloma has evolved over the years with advances in therapy.4

The International Myeloma Working Group (IMWG) consensus criteria for response and minimal residual disease (MRD) assessment was published in 2016, which defines categories of MRD negativity:4

  • Sustained MRD negative
  • Flow MRD negative
  • Sequencing MRD negative
  • Imaging-positive MRD negative

Continued research will help establish the role of MRD in the treatment continuum of multiple myeloma.4

Get an overview of MRD in multiple myeloma

Watch this video for an overview of minimal residual disease (MRD) in multiple myeloma.

ADDITIONAL RESOURCES ON MRD

An educational slide deck on the technical aspects of MRD measurement and incorporating the results into patient management.
Learn more about MRD in hematologic malignancies, including ALL and multiple myeloma, with this brochure.

†††According to a meta-analysis of 14 studies that provided data on the impact of MRD on PFS in 1,273 patients with multiple myeloma, and 12 studies on OS in 1,100 patients with multiple myeloma.16

‡‡‡MRD was measured using the following methods: MFC, ASO-qPCR, or NGS. However, analysis was restricted to techniques with a limit of detection of 0.01% or lower.16

§§§MRD was measured using the following methods: 8-color FCM, 7-color FCM, 4-color FCM, MFC, NGS, and NGF.17

ASO, allele-specific oligonucleotide; AYA, adolescent and young adult; BCI, Bayesian credible interval; CLIA, Clinical Laboratory Improvement Amendments; CT, computed tomography; FCM, flow cytometry; HR, hazard ratio; Ig, immunoglobulin; MFC, multiparametric flow cytometry; N/A, not applicable; NCCN, National Comprehensive Cancer Network; NGF, next-generation flow; NGS, next-generation sequencing; PCR, polymerase chain reaction; PET, positron emission tomography; PFS, progression-free survival; Ph(+), Philadelphia chromosome–positive; qPCR, quantitative polymerase chain reaction; TCR, T-cell receptor; VDJ, variable diversity joining.
